Project details


Sulmara Geo


Bay of Campeche, Mexico


5 Months

  • WROV c/w dual head R2Sonic 2024
  • iXblue ROVINS
  • TSS440
Key Points
  • Removal of a survey support vessel
  • Live “as-built” data during trenching
Download case study south


In order to remove the requirement for a survey support vessel live “as-built” data during trenching was essential.  Positioning algorithms were employed to allow extended layback ROV operations whilst auto processing techniques allowed DoB calculation, based on pre-trench pipe position.


While working with a client in the Gulf of Mexico, Sulmara Subsea was able to improve the speed of delivery of “as-trenched” survey work, as well as reducing overall vessel time spent, by performing simultaneous trenching and survey operations.  The survey team on board identified that the vessel configuration would allow the ROV to fly behind the jet trencher, at a suitable offset, to allow trenching and the “as-trenched” survey to be completed in a single pass.  This not only negated the need for a separate survey pass, but also enabled the project engineers and trenching supervisors to access data relating to the performance of the trencher in (almost) real-time, thus facilitating effective decision making and fostering confidence in trencher performance.


The overall project duration was reduced by approximately 25%.  The client was impressed with the correlation between the simops survey DoB and conventional “as-trenched” survey results.  Further confidence in the system came from continually comparing numerous passes on different pipelines before dropping traditional methodology in favour of innovation.

“This is a prime example of the approach we take when it comes to challenging legacy methodology and quantifying results in the field through real-life comparisons. Our team is encouraged to do this at every opportunity so we can deliver tangible cost savings to our clients and, ultimately reduce our impact on the environment.”
Kevin McBarron
CEO, Sulmara Subsea
